SMARTER, FASTER, STRONGER.
World-first layflat permanent formwork.
Rise Wall Water Resistant
For builders and form-workers frustrated by the bulky nature of permanent formwork, Rise Wall is the first permanent formwork manufactured in a lay-flat format. Compact until opened to install, Rise Wall significantly reduces transport and material handling, is easier to cut and faster to install, making it the most cost-effective permanent formwork on the market.
Rise Wall Water Resistant is the world’s first lay-flat permanent formwork. Constructed from a PVC composite plastic material, Rise Wall Water Resistant provides superior resistance to water and other liquids, making it ideal for basements, lift shafts, retaining walls, internal party walls, blade walls, OSD tanks, and a range of commercial, industrial and agricultural applications.
The Rise Wall system maintains a high level of industry safety and compliance, including fire resistance, thermal rating and acoustic testing. It can be on site within two days from placing the order and is cost-effective for both metropolitan and regional shipping.
With reduced transport, waste removal and panel costs, combined with site and installation efficiencies, Rise Wall Water Resistant saves 30% on your formwork budget.
UVP break outs
Internationally Patented Design
Water Resistant lay-flat design replaces six truck deliveries into one
Short Lead Times
On site within two days from placing the order
Reduce Labour & Equipment
Reduces bulk and waste removal on site.
On site within two days from placing the order Cost-effective for both metropolitan and regional shipping
Certified & Compliant
Easily cut and customised in its lay-flat position to meet changing site requirements
PVC concrete forms have been available in Australia for over 20 years becoming common place for in situ concrete walls.
Compact until opened to install, Rise Wall significantly reduces transport, material handling, and waste removal compared to other in situ concrete formwork systems.
Lay-flat format is easier to cut and faster to install, making Rise Wall the most cost-effective permanent concrete formwork on the market.
Constructed from high quality PVC, Rise Wall Water Resistant is the ideal concrete formwork to build concrete walls, lift & stair shafts, columns & blade walls, retaining walls and external walls.
PVC concrete formwork provides water resistance to concrete walls, making Rise Wall Water Resistant ideally suited to basements walls, retaining walls, external walls and tanks & pits.
Rise Wall’s lay-flat format is 4-5 times more compact than other PVC concrete formwork saving up-to 60% cost on transport and waste disposal.
Rise Wall is easier to cut making it the fastest concrete formwork and most competitive in situ concrete wall and retaining wall systems.
Not requiring shop drawings and prefabrication makes Rise Wall faster and more flexible than other concrete wall panel and external wall panel systems.
|RW Water Resistant||200 Series|
|Standard Heights||2.8m, 3.0m, 3.2m, 3.6m|
|Custom Heights||Available in 200mm increments|
|Fire Resistance||4 Hours|
|Thermal Rating||R 0.49|
|Suitable Applications||All elements Class 1-10
All elements excluding facades Class 2-9
|Acoustic Rating||Rw+ctr >= 50 criteria of Partf5.5 of the NCC wall in Class 2 or 3 building|
Innovative Compact Design
Deliver and store up to 5 times more concrete formwork per SQM, saving you space on site and reducing the cost of delivery of concrete walls.
Short Lead Times
Rise Wall comes in standard sizes, reducing lead time of concrete wall panels and external wall panels and giving the flexibility of in situ concrete and concrete formwork
Reduced Labour & Equipment
Reduced labour and equipment install Rise Wall makes it one of the safest concrete formworks and reduces logistical challenges of in situ concrete and concrete forms
Rise Wall is the most cost effective concrete formwork for basement wall, retaining walls, external walls, and in-situ concrete walls
Certified & compliant
Rise Wall is fully tested & certified and complaint with concrete formwork standards.
Rise Wall can be used in the construction of basement walls, retaining walls, internal party walls external walls, and onsite detention (OSD) tanks.9
Rise Wall can be used as basement retaining wall system, lift & stair shafts, columns & blade walls, external walls, planters & balcony upstands and tanks.9
Rise Products is ideal for external wall panels, basement retaining walls, external retaining walls and onsite detention (OSD) tanks in construction of factories and industrial workshop spaces.
Get a Quote For Your Project
Industrial OSD Tank
Charles Street, St Marys, 2760, NSW, Australia
The construction of a large On-Site Detention Tank (OSD) for a multi-unit industrial estate. The tank spans twelve metres long and nine metres wide and included numerous supporting internal walls, pump out pit and overflow weir.
Industrial OSD Tank
Cabramatta Road, Cabramatta, 2166, NSW, Australia
The construction of a large On Site Detention Tank (OSD) for an industrial estate. The tank spans twelve and a half metres long and nine metres wide and included numerous supporting internal walls, pump out pit and overflow weir.
Residential Home, Underground Living Space
Nowland Street, Seven Hills, Sydney, 2174, NSW, Australia
The project aimed to provide a generous size family home with a large multi-car garage, basement living room and bathroom designed to evolve with the family.
“Really impressed with the product's ease of installation and the support my team received throughout the entire project, from ordering to construction. It was our first time using this product and I would highly recommend it!”
"Our site team had limited experience with formwork of this kind,
however, they completed the
installation within a few days. If we had used conventional formwork systems, we would have been waiting for weeks to complete this amount of work. “
“The standardised panel format meant we did not need to undertake shop drawings, nor was there long lead time for custom fabrication. We just order the materials, they arrive, and a crew with some carpentry skill can start putting panels up.”
All Your Questions, Answered.
We offer technical training and support to all of our customers. Here are just some of our most common questions, if you still have more click the button below.
How much lead time do I need to make an order?
Rise Products holds significant stock of its standardised panels giving us the ability to deliver within 24 hours of order confirmation to selected areas.
Is Rise Wall Industry Compliant?
Is the Rise Wall System Waterproof?
Can Rise Wall Have Internal Services and Insulation?
Can I customise Rise Wall to my Project?
Does Rise Wall need to be braced?
Rise Wall requires bracing during assembly prior to concrete filling. Bracing is done using formwork props fixed to every second panel joing 2/3 of the pannel height.
